Features
SPE series is inverter combined with solar charge controller and ac charger., it’s a professional solution for the off-grid solar system. With the pure sine wave output, no matter the coffee machine, microwave, TV, satellite, printer or other equipment, SPE series inverter charger gives the perfect performance of running loads from household appliances to office devices.
This multi-function inverter, combining functions of inverter, battery charger and auto transfer switch to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operations such as battery charging current, acceptable input voltage based on different applications.
Product Features:
● Stack parallel and three-phase support with up to 6 units (Available for 4KVA/5KVA only)
● Pure sine wave output for sensitive and motor loads
● Built-in PWM 50A solar or MPPT 60A solar charger
● Smart LCD setting (Working modes, Charge Current, Charge Voltage, etc.)
● Auto switch between Utility AC and Battery with minimum 10 milliseconds as UPS
● Programmable AC Under-Voltage(90~280VAC) shutdown to operate under weak shore power
● Gen starter gives boost signal to start back up generator for emergency
● Cold start function
● Support USB, RS485 monitoring function with specific software
4kva / 5kva hybrid inverter specification:
Rated power: 4000va / 3200w( for 4kva).5000va / 4000w ( for 5kva)
Surge power: 8000va / 6400w( for 3kva).10000va / 8000w( for 5kva)
waveform: pure sine wave
Battery system voltage: 48VDC
AC Output voltage: 220v/230v/240v+/-3%
Efficiency(peak): 93%
Transfer Time: 10ms(UPS), 20ms(APL)
Battery Rated Voltage: 48VDC
Battery Overcharge Protection:60VDC
MPPT solar charge current: 60A
PWM solar charge current: 60A
Weight: 10-14kg
